scrap metal shears with double-cylinders

Posotion：Home > Products > scrap metal shears with double

Product name：scrap metal shears with double-cylinders: Product features：1. Scrap metal pulverizers with double-cylinders cooperating with long-arm excavator can complete pulling down and demolition works excellently for high-rise steel houses, it can also be used to cut and demolish scrap metal, sectional material and tubular product accompanying with standard arm length excavator, which is one of indispensable demolition tools especially in chemical plant, steel plant and power plant and finishes splitting and refinement works for worn-out cars, steamships and trains 2. It is two to three times as quick as quartering hammer, realizing fully mechanization, safety and time-saving without using open fire to conduct demolition of steel. 3. Low noise without vibration meets the environmental requirements. 4. With large opening, major diameter cylinder with large bite force, rotate in 360 degrees, tricolpate slewing bearing secure rotary table fastness, built-in plane bearing optimizes the flexibility and convenience of rotation. 5.It is equipped with adjustable blade, a piece of blade can be used several times. 6.Double-jaws are provided with high hardness and wear resistance steel featured with high-wearing resistance, long service life and higher economic profit. 7.Hydraulic cylinder is mounted with protecting cover to block flying debris, special design help pipe be convenient to maintain. 8.Added oil circuit acceleration valve accelerates biting speed and improves working efficiency.

【Function introduction】

Specifications, models and technical parameters

Model：scrap metal shears with double-cylinders
Specifications	JQFGJ-220C	JQFGJ-260C	JQFGJ-35C
Hydraulic shear weightkg	1700	1900	2200
Maximum opening sizemm	650	750	850
Usage flow(1/min)	200-240	240-280	280-320
Applicable excavator tonnage	20-24	25-28	30-36
Hydraulic cylinder stroke	240	240	240
note：According to the different working conditions of customers, more thrust cylinders can be selected for crushing operation.

产品视频

Product details
The use of double cylinder scrap steel dismantling clamp and long arm excavator can accomplish the work of upside down and demolition of high-rise steel frame buildings, and can also be used with standard arm excavator for shearing and demolition of various scrap steel, profiles and pipes. Especially for chemical plants, steel plants, power plants and other demolition operations, it is one of the indispensable demolition tools, and also for all kinds of waste. Old automobiles, ships and trains are divided and refined.
The work efficiency is two to three times that of the crushing hammer. The operation is fully mechanized, safe and time-saving, and there is no need to use open fire for the removal of steel.
Low noise and no vibration, meet the requirements of environmental protection.
